Adinox Overseas is a renowned supplier and exporter of high-performance Hastelloy B3 Flanges, offering unmatched resistance to hydrochloric acid and other aggressive media. These flanges are manufactured in accordance with ASTM B564 and conform to the universal material specification UNS N10675. Known for their superior strength, excellent fabricability, and resistance to pitting and stress corrosion cracking, Hastelloy B3 Flanges are the preferred choice for a wide range of demanding industrial environments including chemical processing, aerospace, pharmaceuticals, and marine industries.

Table Of Contents

Hastelloy B3 is a nickel-molybdenum alloy that exhibits superior thermal stability compared to its predecessor alloys. This enhanced stability allows for greater ease in fabrication and welding, minimizing the risk of cracking during processing. Adinox Overseas provides a comprehensive range of Hastelloy B3 Flanges, including weld neck flanges, blind flanges, slip-on flanges, socket weld flanges, and threaded flanges, all precision-engineered to meet the highest quality standards. These flanges are available in varied pressure ratings and sizes, customizable as per project requirements.

Hastelloy B3 Flanges Hastelloy B3 Flanges Manufacturers, Hastelloy B3 Flanges Suppliers, Hastelloy B3 Flanges Stockists, Hastelloy B3 Flanges Exporters

Adinox Overseas ensures that each flange undergoes strict quality control, including hydrostatic testing, PMI testing, and third-party inspections. All supplied materials come with a Material Test Certificate (MTC) in accordance with EN 10204 3.1 or 3.2 standards, guaranteeing complete traceability. With a commitment to delivering excellence and timely service, Adinox Overseas has established itself as a trusted partner for industries requiring specialized alloy flanges.

Hastelloy B3 Flanges in India, Hastelloy B3 Flanges Manufacturers in India, Hastelloy B3 Flanges Suppliers in India, Hastelloy B3 Flanges Stockists in India, Hastelloy B3 Flanges Exporters in India

The ASTM B564 Hastelloy B3 Flanges supplied by Adinox Overseas are exported to several countries and have gained high demand due to their reliability, mechanical performance, and corrosion resistance. These flanges are widely used in chemical reactors, heat exchangers, pressure vessels, and pipe systems where aggressive acids are processed.

Hastelloy B3 Flanges in Mumbai, Hastelloy B3 Flanges Manufacturers in Mumbai, Hastelloy B3 Flanges Suppliers in Mumbai, Hastelloy B3 Flanges Stockists in Mumbai, Hastelloy B3 Flanges Exporters in Mumbai

Specifications Of Hastelloy B3 Flanges

Specifications	ASTM B564 / ASME SB 564 / 160 / 472
Standards	ANSI Flanges, ASME Flanges, DIN Flanges, EN Flanges, BS Flanges, JIS Flanges, AWWA Flanges etc.
Dimensions	ANSI/ASME B16.5, B 16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, etc.
Size	1/2″NB TO 60″NB
Pressure / Class	150#, 300#, 600#, 900#, 1500#, 2500#, PN6, PN10, PN16, PN25, PN40, PN64
Flange Face Type	Flat Face (FF), Raised Face (RF), Ring Type Joint (RTJ)

Chemical Composition for Hastelloy B3 Flanges

Grade	C	Cr	Mo	Si	V	Fe	Ni
Hastelloy B3	0.010 max	20 – 22.5	12.5 – 14.5	0.08 max	0.35 max	2 – 6	Bal

Mechanical Properties Of Hastelloy B3 Flanges

Element	Density	Melting Point	Tensile Strength	Yield Strength (0.2%Offset)	Elongation
Hastelloy B3	8.69 g/cm3	1399 °C (2550 °F)	Psi – 1,00,000 , MPa – 690	Psi – 45000 , MPa – 310	45 %

Application Of Industries

Power Plants

Aerospace

Refineries

Construction

Oil & Gas

Sugar

Chemical

Petrochemical
